Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Liquid Gas Vaporizer
Gasifying Capacity: 50 to 400 KG/H

Gasifying Capacity: 50 to 400 KG/H

Boiler Power: 380V 3Phase 50Hz

Boiler Power: 380V 3Phase 50Hz

Pressure: ≤1.76Mpa

Pressure: ≤1.76Mpa

Fuel: liquid gas

Fuel: liquid gas

  • Description
  • Parameter
  • pictures
  • Related Products
  • INQUIRY
  • Description

    Brief Introduction

    • Liquefied gas vaporizer is a device that converts liquid gas to be gaseous state by forced heating. It can ensure a continuous and safe gas supply to gas-consuming equipment and reduce residual liquid gas in the cylinders.

    The Features

    a. Energy Saving and Environmental Protection: vaporizers do not require additional energy consumption during operation and do not produce pollution, which is environmentally friendly.

    b. Easy to Install and Maintain: The structure is relatively simple, and the installation and maintenance are convenient, which can reduce the cost and workload of use.

    c. High Heat Transfer Efficiency: usually use high-quality heat transfer materials and reasonable structural designs to increase the heat transfer area and improve the heat transfer efficiency, ensuring the rapid vaporization of liquid gas.


    Parameter
    Model

    QHL50

    QHL100QHL150QHL200QHL300QHL400
    Heating Power(KW) 5 1521 274155
    Gasifying Capacity
    (KG/H)
    50100150200300 400
    Working Pressure(Mpa)≤1.76≤1.76 ≤1.76≤1.76≤1.76≤1.76
    Working Temperature(℃) ≤90 ≤90≤90≤90 ≤90≤90
    Power Source380V 3Phase 50Hz
    Applicationconvert liquid gas to gaseous gas
