As energy conversion equipment, industrial boilers should achieve the highest possible conversion efficiency. However, heat loss is difficult to avoid in the operation of an actual boiler system. What is boiler heat loss? Which factors influence it? The following is a detailed explanation.

I.What is boiler heat loss?

During boiler operation, not all of the heat released from fuel combustion is converted into steam or hot water. The heat that 'escapes' constitutes boiler heat loss.

II.Five core factors affecting boiler heat loss

• -Flue gas heat loss (q2):Higher flue gas temperature and greater flue gas volume result in greater losses.

• -Chemical Incomplete Combustion Loss (q3): Insufficient furnace dimensions and poor fuel-air mixing lead to unburned combustible gases being discharged.

• -Physical incomplete combustion loss (q4): Unburned particles carried by solid fuels (e.g. coal) are discharged with ash or fly ash.

• -Heat Dissipation Loss (q5): Heat lost to the surrounding air through surfaces such as boiler walls and pipes that exceed the ambient temperature.

• -Physical heat loss in ash (q6): Heat carried away by high-temperature ash during discharge.

III.Causes and effects:

High flue gas temperature, an excessive air ratio, an insufficiently sized furnace and poor insulation all increase heat loss.

This directly reduces boiler efficiency, thereby increasing fuel consumption and operating costs.

IV.Improvement measures:

Optimise combustion air distribution to reduce the excess air ratio.

Lower the flue gas temperature and recover waste heat (e.g. through economisers, air preheaters or condensers).

Upgrade furnace wall insulation materials to minimise heat dissipation.

Adopt advanced combustion technologies to ensure complete fuel combustion.

During boiler operation, timely monitoring and prompt corrective action can effectively reduce heat loss and enhance boiler efficiency.
